  • 400mesh/500 mesh stainless steel purcase order Purchase Order

    The purchase order from USA clients





    Our othe products specification forms as bellow:



    Mesh  Wire  diameter Aperture Opening rate Weight
    inch mm inch mm % lb./100ft2
    1x1  0.08 2.03 0.92 23.37 84.6 41.1
    2X2  0.063 1.6 0.437 11.1 76.4 51.2
    3X3  0.054 1.37 0.279 7.09 70.1 56.7
    4X4  0.063 1.6 0.187 4.75 56 104.8
    4X4  0.047 1.19 0.203 5.16 65.9 57.6
    5X5  0.041 1.04 0.159 4.04 63.2 54.9
    6X6  0.035 0.89 0.132 3.35 62.7 48.1
    8X8  0.028 0.71 0.097 2.46 60.2 41.1
    10X10  0.025 0.64 0.075 1.91 56.3 41.2
    10X10  0.02 0.51 0.08 2.03 64 26.1
    12X12  0.023 0.584 0.06 1.52 51.8 42.2
    12X12  0.02 0.508 0.063 1.6 57.2 31.6
    14X14  0.023 0.584 0.048 1.22 45.2 49.8
    14X14  0.02 0.508 0.051 1.3 51 37.2
    16X16  0.018 0.457 0.0445 1.13 50.7 34.5
    18X18  0.017 0.432 0.0386 0.98 48.3 34.8
    20X20  0.02 0.508 0.03 0.76 36 55.2
    20X20  0.016 0.406 0.034 0.86 46.2 34.4
    24X24  0.014 0.356 0.0277 0.7 44.2 31.8
    30X30  0.013 0.33 0.0203 0.52 37.1 34.8
    30X30  0.012 0.305 0.0213 0.54 40.8 29.4
    30X30  0.009 0.229 0.0243 0.62 53.1 16.1
    35X35  0.011 0.279 0.0176 0.45 37.9 29
    40X40  0.01 0.254 0.015 0.38 36 27.6
    50X50  0.009 0.229 0.011 0.28 30.3 28.4
    50X50  0.008 0.203 0.012 0.31 36 22.1
    60X60  0.0075 0.191 0.0092 0.23 30.5 23.7
    60X60  0.007 0.178 0.0097 0.25 33.9 20.4
    70X70  0.0065 0.165 0.0078 0.2 29.8 20.8
    80X80  0.0065 0.165 0.006 0.15 23 23.2
    80X80  0.0055 0.14 0.007 0.18 31.4 16.9
    90X90  0.005 0.127 0.0061 0.16 30.1 15.8
    100X100  0.0045 0.114 0.0055 0.14 30.3 14.2
    100X100  0.004 0.102 0.006 0.15 36 11
    100X100  0.0035 0.089 0.0065 0.17 42.3 8.3
    110X110  0.004 0.1016 0.0051 0.1295 30.7 12.4
    120X120  0.0037 0.094 0.0064 0.1168 30.7 11.6
    150X150  0.0026 0.066 0.0041 0.1041 37.4 7.1
    160X160  0.0025 0.0635 0.0038 0.0965 36.4 5.94
    180X180  0.0023 0.0584 0.0033 0.0838 34.7 6.7
    200X200  0.0021 0.0533 0.0029 0.0737 33.6 6.2
    250X250  0.0016 0.0406 0.0024 0.061 36 4.4
    270X270  0.0016 0.0406 0.0021 0.0533 32.2 4.7
    300X300  0.0051 0.0381 0.0018 0.0457 29.7 3.04
    325X325  0.0014 0.0356 0.0017 0.0432 30 4.4
    400X400  0.001 0.0254 0.0015 0.37 36 3.3
    500X500  0.001 0.0254 0.001 0.0254 25 3.8
    635X635  0.0008 0.0203 0.0008 0.0203 25 2.63

    Contact us freely ,Choose Tori , you won't be disappointed !
